Wireless Backup Car Camera
- Product features:
-
• Wireless transmission range - Up to 984ft (300m), ideal for truck, trailer, RV, etc.
• With auto shutter for better protection of lens, suit to use in bad environment such as sandy or heavily snowy weather
• Can work with magnetic base for easy installation
• Convenient camera power supply by a rechargeable battery
• IR night vision
• Waterproof: IP69K; Anti-vibration: 5.9g
• Viewing Angle: 110° (depending on models)
• IR cut filter optional, Auto heater optional, Audio optional
• Working temperature -20°~70°, able to work normally in harsh environment
Details
Spec Data
Image Device | 1/4" COLOR CMOS |
Frame Rate | 25 fps / 30 fps |
Effective Pixels | 1280(H) x 720(V) pixels |
Resolution | 720P |
Pixel size | 3.0µm x 3.0µm |
Scanning System | Progressive Scanning |
Sync. System | Internal |
Gamma Consumption | 0.45 |
S/N Ratio | S/N(a-weighted) 101.6dB |
AGC | Auto |
White Balance | Auto |
BLC | Auto |
| Operation Frequency | 2401MHz ~ 2483MHz(13 channels) or 2401MHz ~ 2473MHz(11 channels) |
Transmitting distance | 300m |
Video Codec | H.264 |
Spread SPECTRUM | DSSS |
Delay | 200ms |
RF Bit Rate | 12Mbps |
Audio | Optional |
Minimum Illumination | 0.1 Lux or 0.1 Lux(with IR） |
Night vision distance | 8-10m |
| Current consumption | Max.360mA (DC12V without heating) or Max.720mA (DC12V with heating) |
| Charging Voltage | DC12V/DC10~32V |
| Operating Temperature | -20℃～70℃, RH 95% MAX. |
| Storage temperature | -30℃～80℃, RH 95% MAX. |
| Lens | 2.1mm(depending on models) |
| Viewing Angle | 110°(depending on models) |
